- DC VOLHTCTAGE (DCV): 200 mV ~ 1000 V, +(0.5%+5)
- AC VOLTAGE (ACV): 200 mV ~ 750 V, +(1.0%+5)
- AC Current (ACA): 200A,+(2.0%+5), 1000A:
- Resistance (Ω): 200Ω / 2KΩ / 20KΩ / 200KΩ / 2MΩ / 20MΩ, +(0.8%+3)
- Temperature: (-40 ~ 1000) °C, (0 ~ 1832) °F ±(1.0%+5)
- Frequency (For CM-2070FT) 100 Hz ~ 10 MHz ±(0.5%+5)
- Dimension : 123(H) x270(W) x 35(D)mm
Warranty:
1 year
Standard Accessories include: Test leads, Battery, Manual, TP01 Temperature probe
Clamps measure current. Probes measure voltage. Having a hinged jaw integrated into an electrical meter allows technicians to clamp the jaws around a wire, cable or other conductor at any point in an electrical system, then measure current in that circuit without disconnecting/deenergizing it.
