DC Voltage
- 400mV 0.10% ±1.0% of rdg + 5 digits
- 4V 1mV ±0.5% of rdg + 5 digits
- 40V 10mV ±0.5% of rdg + 5 digits
- 400V 100mV ±0.5% of rdg + 5 digits
- 600V 1V ±0.5% of rdg + 5 digits
AC Voltage
- 400mV 0.1mV ±1.5% of rdg + 5 digits
- 4V 1mV ±1.0% of rdg + 5 digits
- 40V 10mV ±1.0% of rdg + 5 digits
- 400V 100mV ±1.0% of rdg + 5 digits
- 600V 1V ±1.0% of rdg + 5 digits
AC Current
- 400A 100mA ‹40A±3.0% of rdg + 5 digits
- 600A 1A ›40A±2.0% of rdg + 5 digits
- Dimensions : 230(H) X 80(W) X 37(D)mm
Warranty:
1 year
Clamps measure current. Probes measure voltage. Having a hinged jaw integrated into an electrical meter allows technicians to clamp the jaws around a wire, cable or other conductor at any point in an electrical system, then measure current in that circuit without disconnecting/deenergizing it.
