Channels 2
Bandwidth 100 MHz
Real-time Sample Rate 1 GS/s
Storage Depth 240 kB
Input
Input Coupling DC, AC
Input Impedance 1 MΩ
Probe Attenuator 1 X, 10 X
Highest Test Voltage 40 V (1 X), 400 V (10 X)
Horizontal System
Time Base Scale 50 s/div - 10 ns/div
Vertical System
Time Base Scale 50 mV/div - 500 V/div
Rise Time < 3 ns
Vertical Resolution 8 bit
Voltage Accuracy ± 5%
Frequency Accuracy ± 0,01%
Trigger System
Trigger Mode Auto, Normal, Single
Trigger Type Rising/Falling edge
Measuring System
Automatic Measurements VPP, VP, Vmax, Vmin, Vavg, Vrms, Frequent, Duty +, Duty-, Time +, Time-, Period
Cursor Measurements XY, Y trigger
Math FFT
Signal Generator
Waveform 14 types
Bandwidth 10 MHz (sine), resolution 1 Hz
Vertical Resolution 14 bit
General Specifications
Display color TFT display, 7 inches, 800 × 480 pixels
Warranty:
1 Year
Scientific research, product development, diy
