| DC VOLTAGE (DCV) |
|
| Range |
Resolution |
Accuracy |
| 600mV |
0.1mV |
± (1.0% reading + 5) |
| 6V |
0.001V |
± (0.5% reading + 5) |
| 60V |
0.01V |
| 600V |
0.1V |
| LoZ 0V-600V |
0.1V |
± (2.0% reading + 10) |
| FREQUENCY |
| Range |
Resolution |
Accuracy |
| 10Hz~10MHz |
0.001Hz~1kHz |
± (0.5% reading + 4) |
| TEMPERATURE |
| Range |
Resolution |
Accuracy |
| (-40~1000)°C |
1°C |
<400°C: ± (1.0% of reading +5) ≥ 400°C: ± (1.5% of reading +15) |
| (-40~1832)ºC |
1ºF |
<750°F: ± (1.0% of reading +5) ≥ 750°F: ± (1.5% of reading +15) |
| DV CURRENT (DCA) |
| Range |
Resolution |
Accuracy |
| 60A |
10mA |
± (1.5% reading+5) |
| 600A |
100mA |
| 800A |
1A |
| AC VOLTAGE (ACV) |
| Range |
Resolution |
Accuracy |
| 6V |
0.001V |
± (0.8% reading+5) |
| 60V |
0.01V |
| 600V |
0.1V |
| LPF 0V-600V |
0.1V |
± (4.0% reading+5) |
| LoZ 0V-600V |
0.1V |
± (2.0% reading+10) |
| AC CURRENT (ACA) |
| Range |
Resolution |
Accuracy |
| 60A |
10mA |
± (1.5% reading+5) |
| 600A |
100mA |
| 800A |
1A |
| CAPACITANCE |
| Range |
Resolution |
Accuracy |
| 6nF |
1pF |
± (5.0% reading + 10) |
| 60nF |
10pF |
| 600nF |
100pF |
± (2.5% reading + 5) |
| 6μF |
1nF |
| 60μF |
10nF |
| 600μF |
100nF |
± (5.0% reading + 10)/td> |
| 6mF |
1uF |
| 60mF |
10uF |
Warranty:
As per brand policy
