Parameter HAP11L3000
Output function Analog voltage per country
Isolation function Built-in isolation transformer
Wiring method Input: single-phase two-wire Output: single-phase two-wire
Output: single-phase two-wire
Number of output phases Single-phase two-wire + PE
Output mode Single-phase standard sine wave output
Output voltage 0-300.0V Rated voltage: 220.0V
Voltage setting accuracy Accuracy: ≤0.1% Resolution: 0.1V
Rated current 14A
Output power 3KVA
Output frequency 45-65Hz,
Frequency setting accuracy Accuracy: ≤0.05% Resolution: 0.1Hz
Frequency stability ≤0.05%
Voltage distortion <2% (linear load)
Response time (technology) ≤2ms
Voltage sudden change response time ≤20ms
Crest factor 1.41±0.1
Source voltage effect ≤1%
Load effect ≤1%
Efficiency ＞90%
Display mode 7-inch LCD display
Voltage measurement accuracy Accuracy: 0.2% FS + 0.3% display value Resolution: 0.1V
Frequency measurement accuracy Accuracy: 0.05% Resolution: 0.1Hz
Current measurement accuracy Accuracy: 0.3% FS + 0.5% display value Resolution: 0.1A/1A
Automatic memory function Setting parameters are automatically memorized and automatically recalled on power-up
Shortcut group recall 10 sets of quick-operation parameter groups for fast switching
Real-time adjustment function Real-time adjustment of the output voltage setting in the start-up state
Overload capacity 105% < overload≤ 110% cuts off output after 60 seconds
110% < overload≤ 120% cuts off output after 5 seconds
Protection device Output overcurrent, overload protection, output short circuit protection, overheating protection
Communication interface Standard: USB, RS232, CAN/RS485, Optional: LAN
Input phases Single-phase two-wire + PE
Input voltage range 220V±10%
Input frequency range 50/60Hz
Operating temperature 0~40℃
Operating humidity 20~90%RH (non-condensing)
Size L×W×H (mm) 500×430×132
Weight (Kg) 19.6Kg
Warranty:
As per Brand policy
Suitable for production line testing, quality assurance, and aging testing in fields such as electronics, healthcare, and new energy.
