AC VOLTAGE (ACV)
Range : 600mV – 1000V
Accuracy : ±(1.0% ±3 d) / ±(1.0% ±5 d)
Resolution : 0.1mV – 1V
Input Impedance 10M Ohms
Overload Protection 1000VDC/1000VAC
ACV Frequency range 40Hz-1000Hz
DC VOLTAGE (DCV)
Range : 600mV – 1000V
Accuracy : ±(0.5% ±3 d) / ±(0.8% ±5 d)
Resolution : 0.1mV – 1V
Input Impedance 10M Ohms
Overload Protection 1000VDC/1000VAC
ACV Frequency range 40Hz-1000Hz
AC & DC CURRENT (ACA & DCA)
Range : 60A – 1000A
Accuracy : ±(2.5% ± 10 d)
Resolution : 0.01A – 0.1V
Overload Protection 250VDC or 250VAC RMS
RESISTANCE (Ω)
Range : 600Ω – 60MΩ
Accuracy : ±(1.0% ±5 d) / ±(1.0% ±2 d) / ±(1.2% ±8 d)
Resolution : 0.1Ω – 0.01MΩ
Overload Protection 250VDC or 250VAC RMS
CAPACITANCE
Range : 60nF- 100mF
Accuracy : ±(4.0% ±25 d) / ±(4.0% ±15 d) / ±(5.0% ±25 d)
Resolution : 0.01nF – 0.1mF
Overload Protection 250VDC or 250VAC RMS
NCV ACV > 60V-1000V/50Hz-60Hz
Live Wire AC V>80V-250V/ 50Hz to 60Hz
FREQUENCY (Hz)
Range : 10Hz – 10MHz
Accuracy : ±(0.5% ± 4 d)
Resolution : 0.01Hz – 0.01MHz
Overload Protection 250VDC or 250VAC RMS
TEMPERATURE
Range : -20°~ 1000°C / -4° ~1832°F
DIODE & CONTINUITY
BUZZER : Built-in buzzer will beep if Resistance is less than 50Ω± 30 Ω
DIODE : Display approximate forward voltage of diode.
Warranty:
As per Brand policy
