Model UDP1306C
Output voltage (CH1/CH2) 0~32V
Output current (CH1/CH2) 0~6A
Output power 192W
Display mode 3-window, 4-digit voltage and current high precision display
Resolution Voltage 10mV
Current 1mA
Load regulation Voltage <0.01%+5mV
Current <0.1%+10mA
Power regulation Voltage <0.01%+3mV
Current <0.1%+3mA
Setting accuracy(25℃±5℃) Voltage <0.5%+20mV
Current <0.5%+10mA
Ripple and noise(20Hz~20MHz) Voltage ≤2mVrms
Current ≤3mArms
Temperature coefficient Current/Voltage: ≤300ppm/℃
Voltage rising/falling time delay ≤100ms (10% rated load)
Interfaces USB Host (5V/2A), USB Device, RS-232
Product size 136mm x 194mm x 327mm
Standard accessories USB communication cable, output cables, Power cord
Standard individual packing Carton box
Standard quantity per carton 1pcs
Standard carton measurement 505mm x 270mm x 335mm
Standard carton gross weight 9.6kg
Warranty:
1 Year- UNI-T
Industrial grade DC regulated Power Supply
