Voltage
Load regulation ≤0.1% + 5mV
Linear regulation ≤0.01% + 5mV
Setting resolution HDP135V6S 10mV
Setting precision ≤0.1% + 1 digits
Read back resolution HDP135V6S 10mV
Read back accuracy ≤0.1% + 1 digits
Ripple HDP135V6S 10mVrms
Overvoltage protection (OVP) HDP135V6S 0 ~ 37V ± 0.2%FS
Maximum voltage HDP135V6S 35.2V ± 0.2%
Current
Load regulation ≤0.2% + 3mA
Linear regulation ≤0.2% + 3mA
Setting resolution 1mA
Setting precision ≤0.2% + 3mA
Read back resolution 1mA
Read back accuracy ≤0.2% + 3 digits
Ripple HDP135V6S 5mArms
Overcurrent protection (OCP) HDP135V6S 0 ~ 7A ± 0.2%FS
Maximum current HDP135V6S 6.2A ± 0.2%
AC input 115 Vac ± 10%, 230 Vac ± 10%, 50/60Hz
Working conditions Temperature -10 ° C to 40 ° C, relative humidity ≤80%
Storage conditions Temperature -20 ° C to 60 ° C, relative humidity ≤80%
Cooling Air cooling
Weight HDP135V6S 1.30Kg
Warranty:
1 Year
