Voltage
Load regulation ≤0.1% + 5mV
Linear regulation ≤0.01% + 5mV
Setting resolution HDP1160V4S 0~100V 10mV
100~160V 100mV
Setting precision ≤0.1% + 1 digits
Read back resolution HDP1160V4S 0~100V 10mV
100~160V 100mV
Read back accuracy ≤0.1% + 1 digits
Ripple HDP1160V4S 15mVrms
Maximum voltage HDP1160V4S 162V± 0.2%
Current
Load regulation ≤0.2% + 3mA
Linear regulation ≤0.2% + 3mA
Setting resolution 1mA
Setting precision ≤0.2% + 3mA
Read back resolution 1mA
Read back accuracy ≤0.2% + 3 digits
Ripple HDP1160V4S 10mArms
Overcurrent protection (OCP) HDP1160V4S 0 ~ 4.4A ± 0.2%FS
Maximum current HDP1160V4S 4.1A ± 0.2%
Remote interface RS232 (Female connector)
Baud rate: 2400
Data bit: 8
Stop bit: 1
None Parity check
AC input 115 Vac ± 10%, 230 Vac ± 10%, 50/60Hz
Working conditions Temperature -10 ° C to 40 ° C, relative humidity ≤80%
Storage conditions Temperature -20 ° C to 60 ° C, relative humidity ≤80%
Cooling Air cooling
Weight HDP1160V4S 1.91Kg
Warranty:
1 Year
Industrial Research, Production, Design Testing Jigs
