- DC Voltage 0.1mV ~ 1000V ±(0.5% + 4digit)
- AC Voltage 0.1mV ~ 750V ±(0.8%+ 10digit)
- DC Current 0.1uA ~ 20A ±(1.0% + 10digit)
- AC Current 0.1uA ~ 20A ±(1.5% + 20digit)
- Resistance 0.1Ω ~ 30MΩ ±(0.8% + 3digit)
- Capacitance 10pF ~ 2000uF ±(2.5% + 5digit)
- Frequency 5Hz ~ 30MHz ±(0.5% + 4digit)
- Temperature -40oC～1000oC ±(0.8% + 4digit)
- Dimension: 185(H) x 93(W) x 35(D)mm
Warranty:
1 year
Used for the following: VSD, diode Test., Capacitance, Frequency / Duty Cycle,Temperature and Transistor Test
