Linshang Authorized brand

Linshang LS332 Luminance Meter

SKU: LS0332
Rs. 27,990.00 MRP Rs. 29,950.00 Save Rs. 1,960.00 (7% off) Inclusive of GST-18%
Out of stock Dispatch lead time: Same Day Dispatch MOQ 1 piece Technical datasheet (PDF)
Currently out of stock

Enter your email and we will notify you when this product is available.

The instrument is a multifunctional luminance meter equipped with a spectral sensor. It is designed to measure luminance, flicker frequency, color rendering index (CRI), and correlated color temperature (CCT) of display screens, backlight panels, lighting fixtures, and similar applications. Additionally, the instrument can display the spectral distribution curve, which helps in identifying the type of backlight source.

  • 1 million cd/m² ultra-wide range, multi-parameter measurement
  • Simultaneously measures luminance, flicker frequency, CCT, CRI
  • Replaceable 10mm/20mm dual light tube
  • Displays spectral curve
  • High accuracy, authoritative certification



Product information

Everything you need to know

Technical Specifications

Luminance Wavelength Range          400nm ~ 700nm

Luminance Wavelength Interval       10nm

Luminance Measurement Distance              ≤1m

Luminance Measurement Range     1 ~1,000,000cd/m2

Luminance Resolution           0.01cd/m2

Luminance Measurement Accuracy             ≤±(5%H+2cd/m2)

(H is the standard value, calibrated with the CIE standard illuminant A )

Luminance Unit Options       cd/m2 (default), fL

CCT Measurement Range     1,000 ~ 100,000K

CCT Measurement Accuracy            ±5% (Calibrated with the CIE standard illuminant A)

CRI Measurement Range      0 ~ 100

CRI Measurement Accuracy ±2 (Calibrated with the CIE standard illuminant A)

Flicker Frequency Measurement Range      10 ~ 500 Hz

Flicker Frequency Measurement Distance ≤0.1m

Flicker Frequency Measurement Accuracy ±5%

Test Aperture Diameter          Φ10mm/20mm

Host Size         147.2mm * 72mm * 28mm

Probe Size       Diameter 40mm*Thickness 76mm

Weight About 370g (including batteries)

Display             240*160 Dot Matrix LCD

Power Supply 2 AA Alkaline Batteries

Operating Environment          Temperature 0 ~ 40℃, Humidity <85%RH

Supply Voltage            DC3V

Warranty
1 year

What's in the Box

Luminance Meter Host, Luminance Meter Probe(Standard φ20mm light tube), φ10mm light tube, User Manual, Calibration Report

Application

Test mobile screen, computer screen, LCD Screen, TV Screen
