MetroQ Authorized brand

MetroQ MTQ64103 Variable DC Power Supply Linear- 64V,10A

SKU: MT6403
Rs. 8,830.00 MRP Rs. 9,500.00 Save Rs. 670.00 (8% off) Inclusive of GST-18%
In Stock (10 available) Delivery 2-6 days MOQ 1 piece Technical datasheet (PDF)
Quantity to add



  • Power: 300W wide-range output covering four power/voltage/current combinations
  • Voltage: 0- 64V- Current: 0-10A
  • Built-in isolation transformer for safe, floating output
  • Compact chassis that frees up bench space
  • Triple display shows Voltage, Current and Power simultaneously on one screen
  • Automatic CC / CV (constant current / constant voltage) mode switching
  • Save-once, recall-always memory settings
  • Fine 10 mV / 1 mA setting and readback adjustment
  • OVP / OCP / OTP multiple protection (over-voltage, over-current, over-temperature)



Product information

Everything you need to know

Technical Specifications

Rated Output Voltage 0–64V

Rated Outpt Current  0–10A

Rated power 300W

Load Regulation         ≤33mV (CV); ≤30mA (CC)

Line Regulation           ≤33mV (CV); ≤20mA (CC)

Ripple & Noise – Voltage (Vrms)       ≤60mVrms

Ripple & Noise – Current (Arms)       ≤40mArms

Setting & Readback Resolution        10mV / 1mA

Setting & Readback Accuracy           ≤0.2%+0.2%FS

Transient Recovery Time       ≤5.0ms (10%–90% rated load)

Protection       OVP, OCP, OTP

Display             3 x 4-bit LED

Cooling System           Fan cooling, smart temp-controlled speed

Device Size (W x H x D)           82 x 142 x 226 mm

Weight 1.80 kg

Warranty
1 Year

What's in the Box



  • Power cord (included)
  • User's manual (included)
  • Banana Plug to Alligator Clip Test Leads (optional)



Application

Production line testing and burn-in
