Bandwidth: 500 MHz (−3 dB)
Channels: 4 + EXT
Sample Rate: Up to 2.5 GSa/s (single channel), 1.25 GSa/s (dual channel)
Vertical Resolution: 12-bit high-precision ADC
Record Length: 100 Mpts deep memory
Waveform Refresh Rate: Up to 500,000 wfms/s
Vertical Scale: 500 µV/div to 10 V/div
DC Gain Accuracy: 3% (≤1 mV), 2% (≥2 mV), 1.5% (≥5 mV)
Input Impedance: 1 MΩ || 15 pF, or 50 Ω (selectable)
Trigger Types Edge, Video, Pulse, Slope, Runt, Windows, Timeout, Nth, Logic, RS232/UART, I²C, SPI, CAN, LIN
Bus Decoding RS232 / UART, I²C, SPI, CAN, LIN
Auto Measurements Period, Frequency, +Width, −Width, Rise/Fall Time, Scr Duty, +Duty/−Duty, Vavg, Vpp, VRMS, Overshoot, Vmax/Vmin, Vtop/Vbase, CycRms, Vamp, Preshoot, Std Dev, +PulseCnt, −PulseCnt, RiseCnt, FallCnt, Area, CycArea, Delay/Phase (inter-channel), FRR/FRF/FFR/FFF/LRR/LRF/LFR/LFF
Waveform Math +, −, ×, ÷, &&, ||, ^, !, Integration, Differentiation, Sqrt, Function ops (Lg/Ln/Exp/Abs/Sine/Cosine/Tan), FFT/FFT rms, User-Defined, Digital Filter (low/high/band-pass, band-reject)
Frequency Counter 6-digit counter; max frequency = model analog bandwidth
Voltmeter DC, AC+DC rms, AC rms; 4-digit resolution (ACV/DCV)
Timebase Accuracy ±1 ppm (typ.)
Warranty:
As per Brand policy
Ideal choice for engineers, educators, and electronics professionals who demand accuracy, flexibility, and ease of use.
