DC VOLTAGE
RANGE RESOLUTION ACCURACY
200mV 0.1mV ±(0.7%+5)
2V 1mV ±(0.7%+3)
20V 10mV
200V 100mV
600V 1V
AC VOLTAGE
RANGE RESOLUTION ACCURACY
2V 1mV ±(1.0%+3)
20V 10mV
200V 100mV ±(1.0% +3) V.F.C. mode: ±(4.0%+3)
600V 1V ±(1.2% +3)V.F.C. mode: ±(4.0%+3)
RESISTANCE
RANGE RESOLUTION ACCURACY
200Ω 0.1Ω ±(1.0%+2)
2KΩ 1Ω
20KΩ 10Ω
200KΩ 100Ω
2MΩ 1KΩ ±(1.2%+3)
20MΩ 10KΩ
Warranty:
As per Brand policy
HVAC, Automotive, Research
