Bandwidth: Up to 8 GHz
Analog Channels: 4 channels
Digital Channels (Optional): 16 channels (MSO functionality)
Sampling Rate: Up to 20 GSa/s
Vertical Resolution: 12-bit ADC
Memory Depth: Up to 2 Gpts
Waveform Capture Rate: Up to 1,000,000 waveforms per second
Display: 15.6-inch Full HD touchscreen
Rise Time: ≤ 55 ps
Interfaces: USB, LAN, HDMI, PCIe
Operating System: Windows-based platform
Warranty:
1 year
High-speed digital signal testing
Signal integrity and jitter analysis
Embedded system debugging
UART, I2C, SPI, CAN, LIN protocol analysis
Automotive electronics diagnostics
Communication system testing (Ethernet, USB, PCIe)
Aerospace and defense electronics testing
Semiconductor research and validation
Power electronics and switching analysis
Waveform and frequency analysis
Noise and transient signal measurement
Advanced laboratory and R&D applications
