Linshang LS122 IR Power Meter

The Linshang LS122 is a portable UV intensity meter designed for measuring UV irradiance and UV transmission performance of UV-blocking materials. With a spectral response range of 260nm–395nm and measurement capability up to 40,000 μW/cm², it is ideal for testing UV lamps, UV sterilization systems, UV curing equipment, window films, protective coatings, and UV-filtering materials.

Measures UV intensity from 0 to 40,000 μW/cm²
UV rejection/transmission testing capability
Wide spectral response: 260nm – 395nm
Fast and accurate digital measurement
Large LCD display with easy-to-read values
Portable handheld design
Suitable for UV lamps, UV curing, window films and protective coatings
Battery-powered operation for field measurements
Simple one-button operation

Rs. 13,500.00 /each Save Rs. 3500 (26% Off)

Rs. 10,000.00 /each (Incl GST-18%)

Quantity

Brand
Authorization
Total Brand Orders	2

Dispatched (in Days): Same day dispatch

Minimum Order Quantity: 1 pcs

Country of Origin: N/A

1 In stock Need more?

Warehouse location - Delhi, India.
Delivery - 2-6 Business Days

Technical Specifications

Model: LS122

Measurement Type: UV Intensity & UV Rejection

UV Intensity Range: 0 – 40,000 μW/cm²

UV Rejection Rate: -999% to 100%

Spectral Response: 260nm – 395nm

Resolution: 1 μW/cm²

Display: LCD Digital Display

Power Supply: Battery Powered

Operating Temperature: 0°C – 50°C

Dimensions: Portable Handheld Design

Warranty: 1 year

Uses

• Testing UV intensity of UV curing lamps

• Measuring UV output of UV sterilization and disinfection equipment

• Evaluating UV performance of UV LED light sources

• Testing UV rejection capability of window films and solar control films

• Measuring UV blocking performance of laminated and coated glass

• Quality inspection of UV-protective materials and coatings

• Verifying UV protection efficiency of plastic sheets and acrylic panels

• Research and laboratory UV intensity measurements

• Maintenance and performance monitoring of UV equipment

• Industrial quality control and product testing
