General
- Display: 2.8-inch IPS LCD
- Display Counts: 2000 counts
- True RMS: Yes
- Clamp Opening: 38 mm
- Battery Type: 1 × 18650 Lithium Battery (3.7V)
- Dimensions (L × W × H): 248 × 94.5 × 37.8 mm
- Data Interface: Bluetooth (Mobile App Support)
- Data Storage: CSV export via mobile app
- Auto Power Off: Yes
- Low Battery Indicator: Yes
Multimeter Specifications
DC Voltage
- Range: 20 mV / 200 mV / 2 V / 20 V / 200 V / 1000 V
- Accuracy: ±(0.1% + 5 digits)
AC Voltage
- Range: 200 mV / 2 V / 20 V / 200 V / 1000 V
- Accuracy: ±(0.6% + 10 digits)
DC Current
- Range: 20 A / 200 A / 600 A / 1000 A
- Accuracy: ±(2.0% + 5 digits)
AC Current
- Range: 20 A / 200 A / 600 A / 1000 A
- Accuracy: ±(2.5% + 5 digits)
Inrush Current
- Range: 20 A / 200 A / 600 A / 1000 A
- Accuracy: ±(10% + 10 digits)
Resistance
- Range: 200 Ω / 2 kΩ / 20 kΩ / 200 kΩ / 2 MΩ / 20 MΩ
- Accuracy: ±(0.3% + 5 digits)
Capacitance
- Range: 2 nF / 20 nF / 200 nF / 2 µF / 20 µF / 200 µF / 2000 µF / 20 mF
- Accuracy: ±(3.0% + 5 digits)
Frequency
- Range: 200 Hz / 2 kHz / 20 kHz / 200 kHz / 2 MHz
- Accuracy: ±(0.1% + 5 digits)
Duty Cycle
- Range: 0.1% – 99.9%
- Accuracy: ±(1.2% + 3 digits)
Oscilloscope Specifications
Analog Bandwidth
- Voltage: 1 MHz
- Current: 1 kHz
Channels
Sample Rate
Maximum Input Voltage
Input Impedance
Maximum Current Measurement
Time Base
Sensitivity
Trigger Modes
Trigger Type
Measurement Functions
- RMS
- Period
- Frequency
- Maximum
- Minimum
- Peak-to-Peak
- Average
Sampling Depth
Warranty:
1 Year
Electrical maintenance technicians
Industrial automation engineers
EV and motor diagnostics
