Functions Range Resolution Accuracy
Temperature Measurement -40～120℃ 0.1 ±1℃ (-10～75℃) ±2℃ (others)
–40~248°F 0.2/1 (>100℉) ±2℉(14～167℉) ±4℉(others)
Inclination Measurement –90.0~+90.0 ° 0.1 ±1.5°(-50～+50°)
±2.5°(-85～50°,+50～+85°) ±3.5°(others)
Azimuth Measurement 0~360° 1 ±7°
Data Storage 12800 sets
Storage interval 1s ~ 60min
LED Indicator ✔
Sound Prompts ✔
Auto Power Off 30 minutes (no operations)
Compass Calibration ✔
Mobile APP ✔
Time Setting ✔
Bluetooth wireless transmission distance 100m
Working Height ≤2000 meters
Working Environment -20℃～60℃, ≤90%RH(non-condensing )
Storage Environment -30℃～70℃, ≤80%RH(non-condensing )
IP Rating IP65
Drop Test 2 meters
General Characteristics
Battery 2×AA
Battery Life About 95h
Size 201×54.2×33.7mm
Weight About 212g(Battery not included)
Accessories Solar Irradiance Meter*1, Cloth Bag*1, User Manual*1, Safety Guide*1, AA Battery*2, Suction-Cup Temperature Probe*1, Solar Panel Mounting Bracket*1, General Download Operation Guide*1
Warranty:
As per Brand policy
It is widely used for solar panel installation and maintenance in photovoltaic power stations, as well as for product testing in PV laboratory environments.
