Model NVC-MFV56
Description Camera Tester
Display 5.5 inch OLED touch screen
Resolution 1280 × 720P
Supported Cameras 8MP AHD, TVI, CVI, analog, and IP cameras
Video Format H.265 / H.264 – 4K video display
HDMI Input 1× HDMI (4K @ 30FPS supported)
Coaxial Camera Recognition Automatic camera type and resolution recognition with Auto HD
Image Processing 4× digital zoom, screenshot, video recording, playback
PTZ Control Coaxial PTZ control, OSD menu call
ONVIF Support Fast ONVIF login, image capture, test report creation
DC Power Output 12V / 3A camera power output
PoE Power Output 48V PoE, Maximum 30W
UTP Cable Test RJ45 connection sequence and terminal fault detection
RJ45 TDR Test Cable length, short circuit, open circuit test (max. 600 meters)
Wi-Fi Feature Built-in Wi-Fi + Hotspot creation, wireless camera viewing
Audio Input Test 1 channel audio test (microphone supported)
Audio Test 1 channel audio signal test (microphone supported)
Multimedia Playback 4K video, MKV / MP4 file support
Battery 7.4V 2600mAh Lithium-ion (~3–4 hours charging)
Working Time ~5 hours (full charge)
Power Management Instant monitoring of input/output voltage and power information
Operating Temperature -10°C ~ +50°C
Certification CE, RoHS Certified
Dimensions 183 × 110 × 36.5 mm
Weight 0.8 kg
Color Black Orange
Quantity 1
Warranty:
As per Brand policy
