Hantek HDL2513B+ DC Electronic Loads 120V, 120A

HDL2500 + series oscillating DC electronic loads can display voltage and current waveforms in real time, and support waveform recording, storage and playback, so that signal changes can be clearly seen. Programmable load list, automatic switching according to programmed presets, efficient and accurate. Ripple test function, can accurately assess the power supply ripple noise, LED, battery, short circuit and other simulation functions, simulate the real load conditions. Constant-current, constant-voltage, constant-resistance and constant-power modes can be switched at will to meet various tests.

• The 4.3-inch LCD color display provides users with a clear and intuitive visual experience;
• Resolution up to 0.1mV/1mV/ 0.1mA to accurately test the performance of the device under test;
• Timing control list programming for accurate, high-speed simulation of complex changing currents;
• Equipped with USB/LAN/RS232 interfaces, supporting SCPI protocol, convenient for data interaction and remote control;
• OCP/OPP test, the instrument automatically captures the OCP and OPP points and determines whether the test result exceeds the set specifications;
• With voltage rise/fall time test function and ripple measurement function;
• Voltage and current measurement rate up to 100KHz;
• Remote measurement terminals are provided to compensate for voltage drop across the line and improve remote measurement accuracy;
• Four operating modes: constant voltage/current/resistance/power, easy to simulate a variety of characteristics of loads

Technical Documents - 1
