Hantek HDL2513B+ DC Electronic Loads 500V, 30A, 600W

SKU: HDL253B
Rs. 68,750.00 MRP Rs. 79,200.00 Save Rs. 10,450.00 (14% off) Inclusive of GST-18%
In Stock (1 available) Delivery 2-6 days MOQ 1 piece Technical datasheet (PDF)
Quantity to add

HDL2500 + series DC electronic loads can display voltage and current waveforms in real time, and support waveform recording, storage and playback, so that signal changes can be clearly seen. Programmable load list, automatic switching according to programmed presets, efficient and accurate. Ripple test function, can accurately assess the power supply ripple noise, LED, battery, short circuit and other simulation functions, simulate the real load conditions. Constant-current, constant-voltage, constant-resistance and constant-power modes can be switched at will to meet various tests.

  • The 4.3-inch LCD color display provides users with a clear and intuitive visual experience;
  • Voltage: 500V,  Current: 30A, Power: 600W
  • Resolution up to 0.1mV/1mV/ 0.1mA to accurately test the performance of the device under test;
  • Timing control list programming for accurate, high-speed simulation of complex changing currents;
  • Equipped with USB/LAN/RS232 interfaces, supporting SCPI protocol, convenient for data interaction and remote control;
  • OCP/OPP test, the instrument automatically captures the OCP and OPP points and determines whether the test result exceeds the set specifications;
  • With voltage rise/fall time test function and ripple measurement function;
  • Voltage and current measurement rate up to 100KHz;
  • Remote measurement terminals are provided to compensate for voltage drop across the line and improve remote measurement accuracy;
  • Four operating modes: constant voltage/current/resistance/power, easy to simulate a variety of characteristics of loads

ToolWorld is Hantek Authorized Distributor

Product information

Everything you need to know

Technical Specifications

Model HDL2513B+

Rated value ( 0～40 ℃)

Input Voltage 0~500V

Input Current 0~3A       0~30A

Input Power 600W

Minimum operating voltage 0.3V at 3A           3V at 30A

Constant Voltage mode

Range 0.1~50V         0.1~500V

Resolution 1Mv               10mV

Accuracy   ±(0.05%+0.05%FS)                     ±(0.05%+0.05%FS)

Constant current mode

Range 0~3A     0~30A

Resolution 1mA    1mA

Accuracy   ±(0.05%+0.05%FS)     ±(0.05%+0.1%FS)

Constant resistance mode*1

Range   0.1Ω~10Ω     10Ω~7500Ω

Resolution 16bit

Accuracy 0.01%+0.08S*2                0.01%+0.0008S

Constant power mode*3

Range      600W

Resolution 10mW

Accuracy ±（0.2%+0.2%FS）

Dynamic mode

Dynamic mode

CC mode

T1＆T2 100μS~3600S /Res:1μS

Accuracy 10μS±100ppm

Rise/Fall rate*4 0.001~0.5A/μS          0.01~0.5A/μS

Minimum rise time*5   ≒60uS                  ≒60uS

Measurement range

Voltage readback value

Range           0~50V                0~500V

Resolution  1 mV               10mV

Accuracy ±(0.025%+0.025%FS)   ±(0.025%+0.025%FS)

Current readback value

Range           0~12A     0~120A

Resolution      0.1mA    1mA

Accuracy  ±(0.05%+0.05%FS)     ±(0.05%+0.1%FS)

Power readback value

Range  600W

Resolution 10mW

Accuracy  ±(0.2%+0.2%FS)

Protection range

Overpower protection ≒620W

Overcurrent protection ≒13A            ≒130A

Input terminal impedance 500KΩ

Interface USB,RS232,LAN

Dimension 208.5mm*84.5mm*455mm

Warranty
1 Year

Recommended Uses

Meet different customers' needs from Education, Scientific Research and Manufacturing
