Input 1 x HDMI / DVI (via HDMI adapter)
Max Input Resolution Up to 1080p @ 60Hz
Output 4 x HDMI @ 1920×1080 @ 60Hz
Video Wall Modes 2×2, 1×4, 4×1, 1×3, 3×1, 1×2, 2×1, splitter
Rotation 180° rotation supported
Bezel Compensation Yes
Audio Output 3.5 mm stereo + optical SPDIF
Control Methods Buttons, IR remote, RS-232
Housing Material Black metal
Power Supply ~5 V/2 A or 12 V adapter
Dimensions Approximately 130 × 130 × 25 mm
Weight Approximately 400 g
Operating Temperature 0–40 °C
Certifications CE, FCC, RoHS, HDCP 1.3/1.4
Warranty:
As per Brand policy
Ideal for digital signage, exhibition setups, boardroom displays, or retail window visuals.
