Voltage output range 0-30V
Current output range 0-5A
Current and voltage display model A means pointer display, D means LED display
Display precision Pointer display: ±2.5% Digital display: ±1% ±1 word
Input voltage AC 220V ±10% (switch to choose) 50/60Hz
Operating condition -10˚C ~ 40˚C, ≤ 90%RH
Storage condition -10˚C ~ 40˚C, ≤ 80%RH
Constant voltage working conditions
1. Voltage stability ≤ 0.01% + 2mV
2. Load stability ≤ 0.01% + 2mV
3. Recovery time ≤ 100µs
4. Ripple and noise ≤ 1mVrms (effective value)
5. Temperature coefficient ≤ 200PPM˚C
Constant current working condition
1. Current stability ≤ 0.2% + 3mA
2. Load stability ≤ 0.2% + 3mA
3. Ripple and noise ≤ 2mArms (effective value)
Weight 4.6 KGS
Warranty:
As per Brand policy
For scientific study, product development, laboratory, junior college and electronic production line
