DC VOLTAGE
Range : 600mV – 1000V
Accuracy : ±(0.5% + 3 digits) / ±(0.8% + 2 digits)
Resolution : 0.1mV – 1V
Input Impendence About 10 MΩ
Overload protection 200mV Range : 550VDC or AC Peak Value
Other ranges : 1000V DC or AC 750V peak value
AC VOLTAGE (TRMS)
Range : 600mV – 750V
Accuracy : ±(0.8% + 5 digits) / ±(1.2% + 2 digits)
Resolution : 0.1mV – 1V
Input Impendence About 10 MΩ
Standard sine wave and triangular wave 40Hz–1KHz
Other wave form 40Hz–200Hz
DC CURRENT
Range : 600µA – 1000A
Accuracy : ±(0.8% + 10 digits) / ±(2% + 30 digits)
Resolution : 0.1µA – 1A
Maximum measurement voltage drop 600mV
Overload protection 600µA/6000µA , 0.6A/250V resettable fuse
Positive input terminal VΩ
Negative input terminal COM
AC CURRENT
Range : 600µA – 1000A
Accuracy : ±(0.8% + 10 digits) / ±(2% + 30 digits)
Resolution : 0.1µA – 1A
Maximum measurement voltage drop 600mV
Overload protection 600µA/6000µA , 0.6A/250V resettable fuse
Positive input terminal VΩ
Negative input terminal COM
Standard sine wave and triangular wave 40Hz–1KHz
Other waveform 40Hz–200Hz
RESISTANCE
Range : 600Ω – 60MΩ
Accuracy : ±(0.8% + 5d) / ±(0.8% + 3d) / ±(1% + 25d)
Resolution : 0.1Ω – 10kΩ
Overload protection 550V DC or AC peak value
FREQUENCY
Range : 10Hz – 20Mhz
Accuracy : ±(0.1% + 3d)
Resolution : 0.01Hz – 10kHz
Overload protection 550V DC or AC peak (<10s)
Input sensitivity RMS Effective value 1V
CAPACITANCE
Range : 60nF- 6000uF
Accuracy : ±(3.5%+20d) / ±(5%+10d)
Resolution : 10pF – 1uF
Overload Protection 550V DC or AC peak value
TEMPERATURE
Range : (-50~1000)°C / (0~1832)°F
Resolution : 1°C/ 1°F
Accuracy : ±( 1% + 5) <400°C / ±(0.75% + 5) <750°F
Warranty:
As per Brand policy
It is an ideal tool for industries, radio technology, educational institutions, electricians, engineers, technicians, manufacturers, and for household use.
