DC VOLTAGE
Range : 600mV – 1000V
Accuracy : ±(0.5% + 3 digits) / ±(0.8% + 10 digits )
Resolution : 0.1mV – 1V
Input Impendence About10MΩ
Overload protection 200mVrange: 550VDCorAC peak value
Other ranges: 1000V DC o rAC750V peak value
AC VOLTAGE (TRMS)
Range : 600mV – 750V
Accuracy : ±(0.8% + 5 digits) / ±(1.2% + 10 digits)
Resolution : 0.1mV – 1V
Input Impendence About 10MΩ
Standard sine wave and triangular wave 40Hz–1KHz
Other wave form 40Hz–200Hz
DC CURRENT
Range : 600µA – 6000µA
Accuracy : ±(0.8% + 10 digits)
Resolution : 0.1µA / 0.001mA
Maximum measurement voltage drop 600mV
Overload protection 600µA/6000µA ,0.6A/250V resettable fuse
Positive input terminal VΩ
Negative input terminal COM
Frequency response Sin wave and Triangular wave: 40Hz–1Kz
Other waveform 40Hz-200Hz
AC CURRENT
Range : 600µA – 1000A
Accuracy : ±(0.8% + 10 digits) / ±(2% + 30 digits)
Resolution : 0.1µA – 1A
Maximum measurement voltage drop 600mV
Overload protection 600µA/6000µA ,0.6A/250V resettable fuse
Positive input terminal VΩ
Negative input terminal COM
Standard sine wave and triangular wave 40Hz–1KHz
Other waveform 40Hz–200Hz
RESISTANCE
Range : 600Ω – 60MΩ
Accuracy : ±(0.8% + 5 digits) / ±(0.8% + 3 digits) / ±(1% + 25 digits)
Resolution : 0.1Ω – 10kΩ
Overload Protection 550V DC or AC peak value
Open circuit <3V
FREQUENCY
Range : 10Hz – 20Mhz
Accuracy : ±(0.1%+3 digits)
Resolution : 0.01Hz – 10kHz
Overload protection 550V DC or AC peak (<10s)
Input sensitivity RMS Effective value 1V
CAPACITANCE
Range : 60nF – 6000uF
Accuracy : ±(3.5%+20 digits) / ±(5%+10 digits)
Resolution : 10pF – 1uF
Overload protection 550V DC or AC peak (<10s)
TEMPERATURE
Range : (-50~1000)°C / (0~1832)°F
Accuracy : ±( 1% + 5) <400°C / ±(0.75% + 5) <750°F
Resolution : 1°C / 1°F
Warranty:
As per Brand policy
It is an ideal tool for industries, radio technology, educational institutions, electricians, engineers, technicians, manufacturers, and for household use.
