DC VOLTAGE Range : 600 mV – 600V
Accuracy : ±(1.0% + 2 digits) / ±(0.8% + 3 digits)
Resolution : 0.1mV – 0.1V
Input Resistance About 10MΩ
Max. Input Voltage 600V DC
AC VOLTAGE (TRMS) Range : 6 V – 600V
Accuracy : ±(0.8% + 3 digits)
Resolution : 0.001V – 0.1V
Input Resistance About 10MΩ
Frequency range 40Hz – 400Hz -Response: True RMS
Max. Input Voltage 600V AC (effective value)
AC CURRENT Range : 6 A – 600A
Accuracy : ±(3.0% + 6 digits)
Resolution : 0.01A – 0.1A
Frequency Range 40Hz ~ 400Hz – Response: average value.
Max. Input Current 600A DC
Max. Input Current 600A AC
RESISTANCE Range : 600Ω – 60MΩ
Accuracy : ±(0.8% + 3 digits) / ±(1.2% + 3 digits)
Resolution : 0.1Ω – 0.1MΩ
Open Circuit voltage approx.. 0.4V
Overload Protection 250V DC or AC (valid value)
CAPACITANCE Range : 6nF – 60mf
Accuracy : ± (4.5%+5 digits)
Resolution : 0.1nF – 0.01mF
FREQUENCY Range : 10Hz – 10Mhz
Accuracy : ±(0.5% + 2 digits)
Resolution : 0.001Hz – 0.001Mhz
FREQUENCY (When measuring current, through the clamp) Range : 10Hz – 1kHz
Accuracy : ±(1.5% + 5 digits)
Resolution : 0.01Hz – 0.001kHz
Max. Input Current 600A
Input signal range 4A AC (T-RMS)
FREQUENCY (V-GEAR) (When measuring voltage) Range : 10Hz – >1kHz
Accuracy : ±(1.5% + 5 digits)
Resolution : 0.01Hz – 0.001kHz
Input Resistance About 10MΩ
Input Voltage range 0.2V AC (RMS)
Max. Input Voltage 600V AC (valid value)
TEMPERATURE Range : -50°C ~ 1300°C / -58°F ~ 2372°F
Accuracy : 土1% + 3 digits)
Resolution : 1°C / 1°F
Overload protection 250V DC or AC (valid value)
DIODE TEST
Display approximate forward voltage of diode
• Forward DC Current is about 1mA
• Reverse DC voltage is about 3.3V
CONINUITY TEST
Beeper sounds when resistance is less than 50 OHMS (open circuit voltage about 2.1V)
Warranty:
As per Brand policy
It is an ideal tool for industries, radio technology, educational institutions, electricians, engineers, technicians, manufacturers, and for household use.
