DC VOLTAGE
Range : 6V – 1000V
Accuracy : ±(0.5% + 3) / ±(0.8% + 10)
Resolution : 0.001 V – 1 V
AC VOLTAGE (T-RMS)
Range : 6V – 750V
Accuracy : ±(0.8% + 3) / ±(1.2% + 10)
Resolution : 0.001 V – 1 V
DC CURRENT
Range : 600 µA – 10A
Accuracy : ±(1.2% + 10) / ±(2.0% + 30)
Resolution : 0.1uA – 0.01 A
AC CURRENT (T-RMS)
Range : 600 µA – 10A
Accuracy : ±(1.2% + 10) / ±(2.0% + 30)
Resolution : 0.1uA – 0.01 A
CAPACITANCE
Range : 60 nF – 30 mF
Accuracy : ± (3.5%+20) / ±(5% + 3)
Resolution : 10 pF – 10 uF
FREQUENCY
Range : 10 Hz – 10 MHz
Accuracy : ±(0.1% + 5)
Resolution : 0.01 Hz – 10 kHz
RESISTANCE
Range : 600 Ω – 40 M Ω
Accuracy : ± (0.8%+5) / ± (0.8%+3) / ±(2.5% + 3)
Resolution : 0.1 Ω – 10 kΩ
OPERATING TEMPERATURE
0 ~ 40°C
Warranty:
As per Brand policy
It is an ideal tool for the laboratory, factory, radio enthusiasts and families.
