Range W 0-200
Resolution mW 10
Accuracy 0.1%+0.1%FS
Protection
Over power Protection W >OPP, 10ms delay protect
Over voltage Protection V >OVP, 0.1ms delay protect
Over current Protection V >OCP, 0.1ms delay protect
Over temperature 85℃
Short
CC mode A >20
CV mode V 0
CR mode mΩ 50
AC Parameters
Voltage Range V 110V ±10% or 220V ±10%
Frequency Range Hz 50/60Hz
Interface
RS-232 SCPI support.
General
Heat dissipation Internal intelligent fan with forced air cooling
Safety Complies with European EMC Directive 89/336/EEC for Class A testing and measurement products
Withstand voltage (output to ground) 500V/DC/1mA
Withstand voltage (Input to ground) 1.5KV/AC/5mA
Dimension(LWH) 375mm*215mm*88mm
Weight kg 2
Warranty:
As per Brand policy
