Illumination geometry D/8, specular component include (SCI)
Illumination light source Full spectrum LED light source
Measuring aperture 8mm
Measurement conditions Light source D65, field of view 10°
Measuring time About 1s
Color space CIE Lab, Luv, LCh, Yxy, CMYK, RGB, Hex
Color difference formula ΔE*ab, ΔE*uv, ΔE*94, ΔE*cmc(2:1), ΔE*cmc(1:1), ΔE*00
Repeatability Standard deviation ΔE*ab ≤ 0.03
(Measurement condition: the average value of 30 measurements on the whiteboard at aninterval of 3s after calibration)
Dimension 86mm×62.5mm×158mm
Weight About 245g
Power supply Rechargeable lithium battery3.7V@4000mAh, can measure 10,000 times continuously under full charge
Display 480×320 dot matrix IPS color screen
Language Simplified Chinese, English
Charging port USB (Type-C)
Operating temperature range 0~45℃, 0~85%RH (no condensation)
Storage temperature range -25~55℃, 0~85%RH (no condensation)
Warranty:
As per brand policy
Used in paint, metal, stone, ceramic tiles and plastics industries for color measurement and management, color difference quality control
