Bandwidth 80MHz
Channel 2CH+DMM+AWG
Horizontal
Sample Rate Range 250MSa/s(Single-channel), 125MSa/s(Dual-channel)
Waveform Interpolation (sin x)/x
Record Length 3K samples per dual-channel
SEC/DIV Range 5ns/div~500s/div 1, 2, 5 sequence
Vertical
A/D Converter 8-bit resolution, each channel sampled simultaneously
VOLTS/DIV Range 10mV/div~10V/divat input BNC
Bandwidth Limit, typical 20MHz
Low Frequency Response (-3db) ≤10Hz at BNC
Rise Time at BNC, typical ≤5ns
DC Gain Accuracy ±3% for Normal or Average acquisition mode, 10V/div to 10mV/div
Trigger
Type Edge
Mode Auto, Normal, single
Level ±4 divisions from centre of screen
Trigger Level Accuracy 0.2div × volts/div within ±4 divisions from centre of screen
Slope Rising, Falling, Rising & Falling
Source CH1/CH2
Warranty:
As per brand policy
