IR resolution (Pixels): 320×240
Display 3.5‘’IPS: (640×480)
Field of view(FOV): 56°×42°
Thermal sensitivity(NETD): ≤65mK
Spatial res;olution(IFOV): 3mrad
Frame rate ≤9Hz
Spectral range 8~14µm
Focus Focus Free
Temperature measurement range -40℃~400℃
Accuracy ±2℃ or ±2% whichever is greater
Emissivity 0.01~1.00 adjustable (0.95 default)
Color palettes 7 (White hot, Black hot, Red hot, Ironbow, Rainbow HC, Rainbow, Lava)
Image modes Thermal,Visual image,Fusion,PIP
On screen analyzer 5 Points/1 Line/3 Rectangles/3 Circles
Digital camera resolution 2MP
Digital zoom 2x, 4x
Hi/Lo temperature alarm Icon,LED flashlight
Isotherm Auto/Ratio/Below/Above/Section/Manual
Software analysis PC+APP
Wi-Fi √
General Characteristics
Battery Detachable Li-ion battery pack(3.7V 5200mAh)
Battery operation time ≥ 3 hours (with Wi-Fi off)
USB Type-C
IP rating IP54
Drop proof 2m
Storage 16G Micro SD card
Image/Video storage format JPEG
Certificates CE,UKCA,FCC,RoHS
Product net weight 654g
Product size 260mm×97mm×99mm
Standard accessories Micro SD card, Type-C USB cable, English manual, Li-ion battery pack
Standard carton G.W. 3.6kg
Warranty:
1 Year
Thermal cameras are used in industries such as metals and industrial inspections,
