Infrared image resolution 160x120
Field angle 35°×27°
Image PC offline analysis Support
Infrared detector type Vanadium oxide is uncooled in the infrared focal plane.
Frame rate of thermal images ≤25Hz
Pixel size 12μm
NETD ≤50mK @25ºC, @F/1.1
Shortest focus length 3.2mm
IFOV 3.75mrad
Wavelength coverage 8-14μm
Focus mode Fixed
Temperature measurement range -20ºC to+550ºC (-4ºFto1022ºF)
Resolution 0.1ºC
Temperature measurement mode Centre point / cold hot spot tracking
Emissivity Adjustable from 0.01 to 1.00
Visible light image resolution 300000 pixels
Display screen 2.8″ TFT color display
Image display mode Infrared/visible/dual light fusion
Lighting supplement LED lighting supplement
Store the image / video formats JPG / MP4
Warranty:
As per brand policy
