| Model |
UTi260B |
| General Characteristics |
| IR resolution |
256x192 pixel |
| Screen Display |
2.8”LCD |
| Field of view (FOV) |
56°x 42° |
| Thermal sensitivity (NETD) |
50mk |
| Spatial resolution (IFOV) |
3.8mrad |
| Focus |
Focus free |
| Frame rate |
25Hz |
| Object Temperature range |
-20~550℃ |
| Measurement accuracy |
±2℃ or ±2% whichever is greater |
| Battery operating time |
6hours |
| Functions |
| Palettes |
7 |
| Emissivity |
Adjustable (0.01-0.99) |
| Measurement presets |
Point x3 |
| Digital camera |
648 x 488 pixels |
| Image Model |
Thermal,visible,blending,PiP |
| LED |
√ |
| ROI (eliminates interference) |
√ |
| Auto tracking for Lo/Hi temperature |
√ |
| Alarm |
√ |
| Storage |
16G Micro SD Card |
| PC software |
Analysis, Real-time display |
| Protection |
IP65/2m |
| Communication interface |
Type-C |
| Package |
| Product net size |
236mm x 75.5 mm x 86mm |
| Product net weight |
910g |
| Standard accessories |
Micro SD card, Type-C USB cable, Manual |
Warranty:
1 Year
Air condition maintenance, Heating and ventilation maintenance, Various other industrial use
