MetroQ Authorized brand

MetroQ MTQ32051 Variable DC Power Supply Linear- 32V,5A

SKU: MT3245
Rs. 6,090.00 MRP Rs. 7,500.00 Save Rs. 1,410.00 (19% off) Inclusive of GST-18%
In Stock (30 available) Delivery 2-6 days MOQ 1 piece
Quantity to add



  • Power: 150W wide-range output covering four power/voltage/current combinations
  • Voltage: 0- 32V- Current: 0-5A
  • Built-in isolation transformer for safe, floating output
  • Compact chassis that frees up bench space
  • Triple display shows Voltage, Current and Power simultaneously on one screen
  • Automatic CC / CV (constant current / constant voltage) mode switching
  • Save-once, recall-always memory settings
  • Fine 10 mV / 1 mA setting and readback adjustment
  • OVP / OCP / OTP multiple protection (over-voltage, over-current, over-temperature)



Product information

Everything you need to know

Technical Specifications

Rated Output Voltage 0–32V

Rated Outpt Current  0–5A

Rated power 150W

Load Regulation         ≤33mV (CV); ≤30mA (CC)

Line Regulation           ≤33mV (CV); ≤20mA (CC)

Ripple & Noise – Voltage (Vrms)       ≤40mVrms

Ripple & Noise – Current (Arms)       ≤40mArms

Setting & Readback Resolution        10mV / 1mA

Setting & Readback Accuracy           ≤0.2%+0.2%FS

Transient Recovery Time       ≤5.0ms (10%–90% rated load)

Protection       OVP, OCP, OTP

Display             3 x 4-bit LED

Cooling System           Fan cooling, smart temp-controlled speed

Device Size (W x H x D)           82 x 142 x 226 mm

Weight 1.80 kg

Warranty
1 year

What's in the Box



  • Power cord (included)
  • User's manual (included)
  • Banana Plug to Alligator Clip Test Leads (optional)



Application

Production line testing and burn-in
