Power voltage: 220V.AC/50Hz ±10%
Power consumption : <10W
Display: 3.5” TFT LCD, resolution 480*320
Interfaces: standard: RS232(or 485), USB Device, Handler ;optional :GPIB,USB Host
Service environment: 0°C-40°C
Sizes: 265mm*105mm*305mm (L*W*H)
Weight: 2.1 kg
Excitation source frequency 16 Points (100,120,200,400, 800, 1k, 2k, 4k, 8k, 10k, 15k, 20k, 40k, 50k, 80k, 100k)
Digits Main parameter: 5 digits; secondary parameter: 5 digits
Parameter Main parameter: L/C/R/Z; secondary parameter: x/D/Q//ESR
Range(L) 0.00lµH - 9999H
Range(C) O.OOlpF - 9999µF
Range(R) 0.00010 - 99.99MO
Basic Accuracy 0.10%
Measurement Display Speed 2 times/second (slow), 5 times/second (medium speed), 10 times/second (fast)
Internal Bias 0-1500mV adjustable, lmV stepping
Test Level('{rms) 1oomv,300mV,600mV,lOOOmV,l500mV,2000mV
Correction Function Open circuit correction, short circuit correction
Screening function Tolerance range: -100% - +100%, with fixed points of 10%, 25% and 50%
Selection of comparator Five gear sorting, third gear qualified, one gear failed, one ancillary gear
Communication Interface Standard configuration: USB, RS232 (or 485), Handle interface; Optional: GPIB, USB Host
Warranty:
1 Year
