Insulation resistance (Ω) Test voltages 250V/500V/1000V ±10%
250V 0.05MΩ~200MΩ ±(5%+5)
500V 0.05MΩ~300MΩ ±(5%+5)
1000V 0.05MΩ~500MΩ ±(5%+5)
Load current 250V (R=250kΩ) 1mA ±10%
500V (R=500kΩ) 1mA ±10%
1000V (R=1MΩ) 1mA ±10%
Short circuit current <2mA √
Low resistance continuity Range 0Ω~2000Ω ±(2%+5)
Test voltage Around 5V √
Test current >200mA (R<2Ω) √
Voltage measurement (V) DC voltage 0~440V ±(5%+2)
AC voltage 0~440V
Frequency (For reference only) √
Features
Display count 10000
Manual range √
Phase switch (RCD) 0°and 180° √
Low battery indication √
Auto AC/DC voltage identification √
Red warning lights √
General Characteristics
Power 1.5V battery (LR6) x 6
Display 71mm x 34mm
Product color Red and grey
Product net weight 380g
Product size 160mm x 100mm x 71mm
Standard accessories Batteries, carrying bag, gallus, test leads, alligator clips, test line
Standard individual packing Gift box, English manual
Standard quantity per carton 10pcs
Warranty:
As per Brand policy
It can be used to test insulation resistance, RCD status, low resistance continuity, and voltage measurements.
